AZ797F AC1200 Route

The AZ797F is a dual-band Gigabit Wi-Fi 5 wireless router designed for users. Using the Wi-Fi 5 (802.11ac) standard, dual-band wireless rates up to 1167Mbps (2.4GHz: 300Mbps, 5GHz: 867Mbps); Equipped with dual-band high-gain antenna, it has stronger wall penetration ability and longer transmission distance; Support 100M Ethernet interface to achieve high-speed data transmission; With powerful hardware performance and continuous software OTA upgrades, it comprehensively improves the user's Internet surfing experience.



Model No:. AZ797F
Chipset. RTL8197FH
Wi-Fi Standard. 2.4GHz 802.11b/g/n, 300Mbps
Device Interface. 1x FE WAN+2x FE LAN, 1x Reset / 1x DC Interface
Memory. 8MB Flash+64MB DDR
Antennas. 2x 3dBi 2.4GHz internal antennas
Specification.  105X105X34mm

Product Parameters
Download

Functional parameters
Model name AZ797F
Chipset rtl8197fh+rtl8812fr
Wi-Fi standard 2.4GHz 802.11b/g/n, 300Mbps.
5GHz 802.11a/g/n/ac, 867Mbps
Device Interface 1x FE WAN+2x FE LAN.
1x Reset / 1x DC Interface
Memory (RAM) 8MB Flash+64MB DDR
Antennas 2x 5dBi 2.4GHz external antennas
2x 5dBi 5GHz external antennas
Size 105X105X34mm
Adapter (device) DC 12V/1.5A
protocols TCP/IP, DHCP, ICMP, NAT, PPPoE, ARP, SNTP, HTTP, DNS, H.323, SIP, DDNS, IGMPv1/v2/v3, IGMP snooping, IPv6
WAN Dynamic IP, Static IP, PPPoE, Bridging
Surety Filtering Based on ACL/MAC/URL, DDOS, NAT, Port Mapping, DMZ
Management WEB/TELNET
Appliance DDNS, IGMP Proxy/Snooping, System Log, MESH
Operating Environment Operating Temperature: 0℃～40℃, Operating Humidity: 10%～90%RH Non-condensing
Storage Environment Storage Temperature: -40 ~ +70°C Storage Humidity: 5 ~ 95% Non-condensing
