AZ797G AC1200 Gigabit Routing</trp-post-container

AZ797G AC1200 GE Route

The AZ797G is a dual-band Gigabit Wi-Fi 5 wireless router designed for users. Using the Wi-Fi 5 (802.11ac) standard, dual-band wireless rates up to 1167Mbps (2.4GHz: 300Mbps, 5GHz: 867Mbps); Equipped with dual-band high-gain antenna, it has stronger wall penetration ability and longer transmission distance; Support 1000M Ethernet interface to achieve high-speed data transmission; With powerful hardware performance and continuous software OTA upgrades, it comprehensively improves the user's Internet surfing experience.

Model No:. AZ797G
Chipset. rtl8197fh+rtl8812fr+rtl8367
Wi-Fi Standard. 2.4GHz 802.11b/g/n, 300Mbps 5GHz 802.11a/g/n/ac, 867Mbps
Device Interface. 1x GE WAN+2x GE LAN, 1x Reset / 1x DC Interface
Memory. 8MB Flash+64MB DDR
Antennas. 2x 5dBi 2.4GHz external antennas 2x 5dBi 5GHz external antennas
Specification. 105X105X34mm

Product Parameters

Download

Functional parameters
Model name	AZ797G
Chipset	rtl8197fh+rtl8812fr+rtl8367
Wi-Fi standard	2.4GHz 802.11b/g/n, 300Mbps.

	5GHz 802.11a/g/n/ac, 867Mbps
Device Interface	1x GE WAN+2x GE LAN.
Device Interface	1x Reset / 1x DC Interface
Memory (RAM)	8MB Flash+64MB DDR
Antennas	2x 5dBi 2.4GHz external antennas
Antennas	2x 5dBi 5GHz external antennas
Size	105X105X34mm
Adapter (device)	DC 12V/1.5A
protocols	TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DNS, H.323, SIP, DDNS, IGMPv1/v2/v3, IGMP snooping
WAN	Dynamic IP, Static IP, PPPoE, Bridging
Surety	Filtering Based on ACL/MAC/URL
Management	WEB/TELNET
Appliance	DDNS, IGMP Proxy/Snooping, System Log, MESH
Operating Environment	Operating Temperature: 0℃～40℃, Operating Humidity: 10%～90%RH Non-condensing
Storage Environment	Storage Temperature: -40 ~ +70°C Storage Humidity: 5 ~ 95% Non-condensing
