AZ547G 功能参数
CPU
Dual-Core ARM Cortex-A55 at 1.0GHz
Chip model
RTL9615C
Memory
NAND FLASH 1Gbit(128MB)/DDR4 4Gbit(512MB)
Bob Driver
GN28L98
PON Protocol Specification
The XGS-PON(10G/10G)ITU-T G.9807.1 MAC supports the following features
Supports data rate of:
~10Gbps(9953 Mbps)downstream.
~10Gbps(9953Mbps) upstream. Up to 256 GEM port-IDs.
Up to 40 AlloclDs.
Ranging and activation process support.
Downstream characteristics:
-Downstream AES-128 encryption and key exchange process.
-Downstream FECRS(248216).
-Dedicated independent queues for PLOAM and CPU packets.
Upstream characteristics:
-Upstream AES-128 encryption and key exchange process.
-Upstream FECRS(248216.)
-Normal queues for PLOAM and CPU.
Support ToD synchronization perITU-TG.9807.1.
Support ONU power saving operation perITU-TG.9807.1.
Network Protocol Specifications
ANSI/IEEE 802.3 NWay auto-negotiation
802.1D bridging
VLAN Translation
IP ToS/DSCP to 802.1p mapping
Class of Service based on UNI, VLAN-ID, 802.1p bit, and combination
Marking/remarking of 802.1p
IGMP v2/v3 snooping and IGMP snooping with proxy report
Broadcast/Multicast rate limiting
802.1Q VLAN tagging/un-tagging
Support flexible traffic classification
Support VLAN Intelligent Bridging and Cross Connect mode
Interface
WAN: 1*10G optical interface (APC)
LAN: 1*10/100/1000/2.5G/5G/10G auto MDI/MDI-X RJ-45 ports
LAN:4*10/100/1000M auto MDI/MDI-X RJ-45 ports
LED Indicators
Power, PON/ LOS, INTERNET, 10G LAN, LAN4-LAN1
Power Supply
DC12V 1.0A
Security
Firewall, Dos Protection
WAN Networking
Static IP WAN connection
DHCP client WAN connection
PPPoE WAN connection
Management
Standard OMCI (G.988)
Web GUI (HTTP/HTTPS)
Firmware upgrade via FTP/TFTP/HTTP
Telnet, Web, SSH
CLI command via telnet/console
Two-level administration privilege for web configuration
Configuration backup/restore
TR069
Product Size
150X115X36mm(length X width X height)
Work Environment
Working temperature: 0°C—40°C
Working humidity: 5—95%
