AZ845 N300 4G CPE Router
AZ845 N300 4G CPE Router
AZ845 N300 4G CPE Router
AZ845 N300 4G CPE Router
AZ845 N300 4G CPE Router
AZ845 N300 4G CPE Router

AZ845 N300 4G CPE Router

AZ845是一款配备4G调制解调器的N300 CPE，与IEEE 802.11b/g/n网络保持兼容。

这是一个适用于家庭、宽带通信和小型SOHO的SOHO级网络安全解决方案。



产品特点：

  • 1x 10/100MBASE-T以太网RJ45广域网端口；
  • 3个10/100MBASE-T以太网RJ45 LAN端口；
  • 支持Wi-Fi 2.4G 802.11N 2T2R，速度高达300Mbps；
  • 支持LTE CAT4，上行速度可达50Mbps，下行速度可达150Mbps；

产品参数
资料下载

Chip model MT7628NN+CAT4 LTE Moudle
Memory FLASH 16MB/DDR2 64MB
WiFi Chip Built in MT7628NN
Cellular Frequency LTE-FDD: B1/ 3/ 5/ 8

LTE-TDD: B34/ 38/ 39/ 40/ 41

WCDMA: B1/5/8
WiFi rate 802.11b/g/n Wireless LAN 300Mbps
Interface LAN: 3* 10/100Mbps auto MDI/MDI-X RJ-45 ports

LAN/WAN: 1* 10/100Mbps auto MDI/MDI-X RJ-45 ports

Sim slot：1*nano sim card
Frequency Band 2.4 GHz frequency band 40MHz
Antennas WIFI 2.4G: 2*5dBi External antennas

LTE: 2*3dBi External antennas

Other: 2* Decorative External antennas
Buttons WPS/Reset
LED Indicators Power NET LAN1 LAN2 LAN3 WAN WIFI LTE
Power Supply DC 12V 1A
Product Size 180X110X35 mm (length X width X height)
Work Environment Working temperature: 0°C—40°C；Working humidity: 5—95%
WAN Connection Support DHCP, PPPoE and Static IP address three internet access models,
Wireless Function WiFi basic function, WiFi advanced function, Guest network,
Wireless Encryption WPA/WPA2, WPA2
Management Function WEB
System Maintenance Device management, Configuration management, Upgrade management, Log function, Status statistics, Restart/reset
Advanced Function Firewall, Virtual server,IPV6, UPnP
Certification CCC,SRRC,CTA certification

AZ845-Single N300 4G CPE Datasheets -20240828
